    Zinsco Breakers Over the Years

    Zinsco Breakers New and Used

    Zinsco was one of the early names in the circuit breaker industry. It all began in 1891 when Frank Adam Electric began manufacturing electrical panels and circuit breakers in their St. Louis, Missouri plant. In 1928, sales rep Emile Zinsmeyer introduced their product line to the west coast operating out of Los Angeles.

    Zinsmeyer eventually purchased the west coast distribution under the Zinsmeyer Company name, which continued to operate until 1943 when he sold the business to his son Martin. Martin renamed the company Zinsco Electric Company and began redesigning and patenting their signature "Magnatrip" designs.

    Zinsco was purchased by GTE-Sylvania in 1973. They kept the product the same but relabeled it, dropping the "Magnatrip" label. The line name changed again in 1978, and Zinsco designs became part of the Challenger line. GTE-Sylvania sold all electric distribution product lines and manufacturing plants in 1981. The new owner, Challenger Electrical Equipment Corporation, ceased all Zinsco production except for a re-branded circuit breaker line. They sold to Thomas & Betts (T&B) in 1994, who continued selling the re-branded line until 2005, at which point they destroyed all molds for their Zinsco line. It was at that point the Zinsco line as we all knew it, was dead.

    But that wasn't the end for Zinsco.

    Old And Refurbished Are No Longer Your Only Option

    The demand for old, refurbished, and old but never used Zinsco products and parts was evident immediately following the death of the brand. Breakers could still be found but the market was competitive, and the prices were high (Bay Power still carries a huge inventory of reconditioned Zinsco breakers). This is why in late 2005, Zinsco-style breakers began being manufactured under the Connecticut Electric brand, known as the UBIZ series of breakers.

    This is not a new line of products, but a modern and compliant replacement for the original Zinsco panels to meet current safety specs. Their line of replacement breakers is designed specifically to fit the old Zinsco and the later Zinsco-style GTE/Sylvania panels. We still have some old and refurbished options here at Bay Power, but we also sell the Connecticut Electric UBIZ breakers.

    Why Zinsco Remained In Demand

    Even with their many re-brands, Zinsco maintained a strong following. They have always been a nationwide brand, but they were most prominent as the go-to breakers of choice as California and the west coast began to thrive. In 1963 they produced the R-38 twin breaker which was revolutionary because it made contact on both bus-bars for 240 volts in a single breaker. This advancement is why they thrived and grew in popularity through in the 60s and 70s. However, there were some serious design flaws and safety concerns.

    Safety Hazards Of Zinsco Breakers Resolved

    One of the many reasons Zinsco was discontinued was because their old design fell short of modern safety standards. While they look the same, the re-branded product line from Connecticut Electric UBIZ these safety concerns have been eliminated. This has many bidding goodbye to refurbished replacement parts and upgrading to the newer generation. Here are just a few reasons to upgrade your old Zinsco part:

    Failure To Trip — even in their prime, both the Zinsco and Zinsco-Sylvania breakers would fail to trip. This can lead to an electrical arc explosion that blows out the side external casing which is a tremendous fire and safety hazard.

    Failure To Drop Power — when the need arises to turn off a Zinsco breaker, you cannot rest assured that the current will cease. There have been many situations in which the breaker has been switched off, but the internal breaker is still conducting. This is another safety hazard, and one of the many reasons why a licensed electrician familiar with Zinsco is required.

    Aluminum Bus Bar — there are two primary concerns with the bus bar. First, it is prone to corrosion, which can damage the internal components. The second is that it is prone to overheating which can melt the bar and surrounding components.

    Identifying Authentic Zinsco Breakers

    With so many re-brands it takes an expert to identify authentic Zinsco breakers. If you want to upgrade but aren't sure if your existing breakers are Zinsco these tips will help.

    Labels

    • Look for a blue and white, blue and silver, green and white, or red on black Zinsco label
    • Look for the embossed Magnatrip label
    • Look for a yellow on black Underwriters Laboratory Label
    • Some are not labeled with any of the above markers, so try to identify with the below identifiers

    Color-Coding

    Many old and refurbished Zinsco breakers are color-coded. While designed to make identifying voltage and swapping out breakers fast and easy, color-coding didn't catch on—so many Zinsco circuit breakers are a solid black. Color-coding for old and refurbished Zinsco parts is as follows:

    • 15 Amp blue
    • 20 Amp red or orange
    • 30 Amp green or light blue
    • 40 Amp grey or light brown
    • 50 Amp black
    • 60 Amp white
    • All Amps could be black (for the full size QC line)

    Unique Design

    They're unique custom build, thick design, and deep-slotted connector openings that press over the bus bar makes Zinscos of every generation and re-brand easy to identify, but you may need to pop them out for inspection.
